AC Manifold Gauge with Vacuum Measuring Range 0 to 1 bar rel and Overload Protection up to 65 bar for R134a R22 R12 (A)

Product description Features:the difference:The for testo 549 does not support , the for testo 550 does. for testo 549 list: main unit, English manual, color box.List of for testo 550: main unit, English manual, two-clamp temperature probe, instrument case.Specification:Shell material: ABS/PA/TPUDimensions: 265 x 135 x 75 mm / 10.43 x 5.31 x 2.95 inchesWeight: Approx. 1000gParameters: Pressure: kPa/MPa/bar/psi, Temperature: ℃/℉/K.Sensors: Pressure: 2 x Pressure Sensors, Temperature: 2 x Measurements. Period: 0.5sInterface pressure connection: 3x7/16" UNF, measurement measurementscope:HP/LP Pressure Range: -100 to 6000 kPa / -0.1 to 6 Mpa / -1 to 60 bar (rel) / -14.7 to 870 psiTemperature Range: -50 to +150 °C / -58 at 302 °FVacuum measuring range (rel): -1 to 0 bar / -14.7 to 0 psiOverload: 65 bar, 6500 kPa, 6.5 Mpa, 940 psiResolution: Pressure Resolution: 0.01 bar / 0.1 psi / 1 kPa / 0.001 MPaTemperature Resolution: 0.1°C/0.1°FAmount of : 60Measurable medium: R114; R407C. R444B; R12. R407F; R448A; R123. R407H; R449A; R1233zd; R408A; R450A; for R1234yf; R409A; R452A; R1234ze; R410A; R452B; R414B; R453a; R125; R416A; All; R422C; R500; R32. R422D; R114 R401A; R424A; R503; R401B; R427A; R507; R402A; R434A; R513A; R402B; R437A; R600a; R404A. R438A; R718 ; R407A; R442A; R744 ()Environmental Conditions: Operating Temperature: -20 to 50°C/-4 to 122°FStorage temperature: -20 to 60℃/-4 to 140℉IP rating: 42Batteries: 4 AA batteries (not included)Display Type: Backlit LCDResponse time: 0.5 secondsPackage includes:A: 1* tableB: 1* meter+3*tube+2*test clamp Manufacturer Contact Information no

• 【Multi-Purpose Air Conditioning Gauge】This digital air conditioning gauge is designed for testing and measuring pressure and temperature of various like R134a, R22, R12, R502, and more.
• 【Easy-to-Read Display】Equipped with a backlit LCD display, this gauge provides clear and accurate pressure and temperature readings. It allows for easy monitoring and assessment of air conditioning systems.
• 【 and Reliable】Made from ABS, PA, and materials, this gauge is built to be tough and long-lasting. Its dimensions of 265 x 135 x 75 mm and weight of approximately 1000g durability and ease of use.
• 【Wide Pressure and Temperature Range】With a pressure range of -100 to 6000 kPa and a temperature range of -50 to +150 °C, this gauge can handle a variety of measurement needs for air conditioning systems. It also has a vacuum measuring range from -1 to 0 bar.
• 【Fast and Accurate Measurements】The gauge features fast response time of 5 seconds, ensuring quick and precise readings. It provides pressure resolution of 0.01 bar and temperature resolution of 0.1°C, allowing for accurate measurements.
